Polished Chrome No-Drill Fixed Panel Glass Clamp
- SKU:
- NDC4CH
- UPC:
- MPN:
- S0GC01CH
- Weight:
- 0.00 KGS
- Shipping:
- Calculated at Checkout
Description
Catalog Number: NDC4CH
Finish: CHROME
CRL No-Drill Fixed Panel Clamps provide an alternative to Clamps requiring drilled holes or notches in the glass. Two nylon tipped set screws are tightened to secure the glass. Mounting screws are also provided for the wall/ceiling/floor. Silicone must also be used for reinforcement along 'all-glass' edges where Clamps are used.
SPECIFICATIONS:
Material: Solid Brass
Glass Thickness Range: 5/16" to 3/8" (8 to 10 mm)
No Glass Fabrication Required (Clamps tighten using nylon tipped Allen screws).
Includes: Gaskets
NOTE: These Clamps are not designed to take the place of Headers or a Support Bar. Contact CRL Frameless Shower Technical Sales Department for more details. Can be used on both square cut or mitered panels.
