U Channel

SDCD12 Shower Glass U Channel for 12mm Glass

SKU:
SDCD12
MPN:
SDCD12
Weight:
0.10 KGS
Shipping:
Free Shipping
  • SDCD12 Shower Glass U Channel for 12mm Glass
  • U Channel 12mm U Channel for Shower Glass Installation
£45.00 - £99.00

All ( in stock) components delivery 1-2 working days
All glass items deliver 7-10 working days - Check here for delivery areas we cover

Description

SDCD12 Uchannel for 12mm glass, Ideal for fixing 12mm glass

Easy to cut and simple to fit our 12mm Uchannel is ideal for bespoke shower configurations when you need to install a wall fitting to accommodate 12mm toughened glass panels. Made with aluminium the channel comes in 2.41m lengths and is easy to cut with a hack saw or other types of cutting tools.

Simply Drill holes required and fit to wall, slide the glass in and silicone.. its that simple.


SKU:               SDCD12XX  (XX = replace with colour code)

  • Recommended Deduction from glass tight size:                  5mm
  • Depth / height of profile wall                                            19 mm
  • Stock Lengths                                                          2.41 metre
  • Thickness of Metal :                                                    2.03 mm
  • Glass is siliconed into place.
  • U Channel for 12mm glass.
  • U Channel is secured in place using screws or silicone. Recommend screwing in place.

Wet Glazed with Silicone to Secure Glass:
CRL Clear EU 33S Shower Sealant 300ml
CRL Crystal Clear Shower Sealant - 310ml Cartridge
CRL Black EU 33S Shower Sealant 300ml
CRL White EU 33S Shower Sealant 300ml

  For help with fitting please see here: https://www.shower-glass.co.uk/how-to-fit-a-shower-screen/

View AllClose

Additional Information

Length:
2.41m
External Width:
17.2mm
Internal Width:
13.1
Depth:
19mm
