Offset Back Plate Hinges

Catalogue Number: GEN044                    Cut-Out Required in Glass, See Template in product images. Includes: Gaskets, Screws, and Glass Fabrication Dimensions Backplate:    ...

Catalogue Number: GEN344 (An adjustable close version the offset hinge GEN044) Deduction: 8 mm from glass width to achieve the same width / coverage. Glass Fabrication: Cut-Out Required in Glass, See Template in product images. Includes: Gaskets,...

Catalog Number: P1N044 Offset Back Plate Tolerance 8mm (The deduction from the glass width to allow for hinges while achieving the same coverage / width.) Glass Thickness: 8 mm to 12 mm Tempered Safety Glass Self-Centering with Reversible 5 Degree...

Catalogue Number: JRG344 Wall Mount Offset Back Plate (Allows Clean Sight Line From Shower Exterior) Adjustable to Any Angle Up to 90 Degree without Having to Take Door Down3 Year Warranty Using two hinges with 6 to 8 mm the hinge will hold up to 28...

Glass Tolerence(reduction from edge of glass) 8mm Using two hinges with 12, 10, and 8mm Glass the hinge will hold up to 45 kg with a maximum door width of 762 mm. Using three hinges with 12, 10, and 8mm Glass the hinge will hold up...

Catalogue Number: V1E344 (An adjustable close V1E044) Glass Fabrication: Cut-Out Required in Glass, See Template in product images. Includes: Gaskets, Screws, and Glass Fabrication Dimensions. Backplate: Offset back-plate, Wall to Glass Hinge...

Catalogue Number:  JRG044     Glass Thickness:    6 mm to 8 mm Toughened Safety Glass         Hinge Swings:  90 Degree in and 90 Degree Out      Closing Type:  ...

Catalog Number: C0L044BR  Finish: Brass Accommodates 3/8" to 1/2" (10 to 12 mm) Glass Available in Several Beautiful Finishes 3 Year Warranty Wall Mount Offset Back Plate Standard Model   Cologne Hinges are similar to the popular Vienna...

Catalog Number: V1E044CH   Finish: Chrome Accommodates 3/8" to 1/2" (10 to 12 mm) Glass Available in Several Beautiful Finishes 3 Year Warranty Wall Mount Offset Back Plate Standard Model Vienna Hinges are the solution for wider, heavier doors...

Catalogue Number: P1N344 (An adjustable close version of the offset hinge P1N044) Glass Fabrication: Cut-Out Required in Glass, See Template in product images. Includes: Gaskets, Screws, and Glass Fabrication Dimensions. Backplate: Central...

Catalog Number: C0L044CH  Finish: Chrome Accommodates 3/8" to 1/2" (10 to 12 mm) Glass Available in Several Beautiful Finishes 3 Year Warranty Wall Mount Offset Back Plate Standard Model   Cologne Hinges are similar to the popular Vienna...

Catalog Number: GRA044   Can be Side Mounted at Top and Bottom Available in Several Beautiful Finishes 3 Year Warranty Wall Mount Offset Back Plate (Allows Clean Sight Line From Shower Exterior) The Grande Hinge incorporates a larger clamping...
