Brass Cologne 044 Series Wall Mount Offset Back Plate Hinge
- 0.90 KGS
- Calculated at Checkout
Catalog Number: C0L044BR Finish: Brass
Accommodates 3/8" to 1/2" (10 to 12 mm) Glass Available in Several Beautiful Finishes
3 Year Warranty
Wall Mount Offset Back Plate Standard Model
Cologne Hinges are similar to the popular Vienna Hinges, but with one change: They have radius corners and beveled edges to provide a sleek appearance. Cologne Hinges are the solution for wider, heavier doors that traditional hinges are not strong enough to support. Two strategically placed steel pins inside the hinge provide template options, and satisfy two schools of thought for mounting shower door hinges. For the safety of "mouse-ears" type cut-outs, the two steel pins should be left in place. This allows the Cologne Hinge to be used with its own "mouse-ears" cut-out. On the other hand, to enable increased adjust-ability, the two pins can be removed. This allows the Cologne Hinge to fit its own rectangular shaped, square cornered cut-out. In some cases, it will also fit competitive rectangular, square cornered cut-outs.
STANDARD REVERSIBLE PIVOT PIN: Each Cologne Hinge contains a Reversible Pivot Pin. One side of the Pin is marked at 90 Degree. The opposite side of the Pin is marked 85 Degree. Standard Cologne Hinges come with the 90 Degree side activated. Pre-Set Models come with the Pin pre-set for 85 Degree (5 Degree tighter closure into shower interior). The Pin can be rotated (not flipped upside down) to activate the other side.
CUSTOM PIVOT PIN: Custom Pivot Pins are available to accommodate "off-angle" installations. As an example, you may encounter a wall that will not meet your door at 90 Degree. If the standard 5 Degree Pivot Pin contained in the hinge does not assist in closing the door to the position desired, you may specify the angle needed for a Custom Pivot Pin (up to 45 Degree). Using two hinges with 3/8" to 1/2" glass (10 to 12 mm) the hinge will hold up to 100 lbs. (45 kg) with a maximum door width of 32" (813 mm). Using three hinges with 3/8" and 1/2" glass (10 to 12 mm) the hinge will hold up to 130 lbs. (59 kg) with a maximum width of 32" (813 mm).
SPECIFICATIONS: Glass Thickness: 3/8" (10 mm) to 1/2" (12 mm) Tempered Safety Glass Construction: Solid Brass Hinge Swings: 90 Degree In and 90 Degree Out Closing Type: Self-Centering when within 15 Degree of closed position. Cut-Out Required - Except C0L092 Which Requires Cut-Out for Door and Two Holes for Fixed Panel Includes: Gaskets, Screws, and Glass Fabrication Dimensions
