Magnetic Profile

90 Degree Magnetic Door Seal for 6mm and 8mm Glass

SKU:
PMC8
Weight:
0.20 KGS
Shipping:
Calculated at Checkout
£29.38

All ( in stock) components delivery 1-2 working days
All glass items deliver 7-10 working days - Check here for delivery areas we cover

Description

Catalog Number: PMC8

Provide Positive Door Closure
Mix and Match Configurations to Achieve Desired Result
Made of Co-Extruded Plastic with Soft Magnetic Receiver
Models for 1/4" to 5/16" (6 to 8 mm) Thick Glass
Suggested Gap: 7/16" (11 mm) Paired Gap: 22mm

This CRL Magnetic Profile/ door seal provides positive door closure for glass-to-glass applications. It is made of co-extruded material with soft magnetic receiver and will accommodate 1/4" to 5/16" (6 to 8 mm) Glass.



Suggested Gap: 7/16" /  11m         (11 mm each receiver, 22m if Paired)



APPLICATION:
180 Degree Glass-to-Glass: Use PMA10 and PMB10 (Door swings in one direction)
180 Degree Glass-to-Glass: Use PMC10 and PMC10 (Door swings in both directions)
135 Degree Glass-to-Glass: Use PMA10 and PMC10 (Door swings out only)
90 Degree Glass-to-Glass: Use PMA10 and PMB10 (Reverse for polarity-door swings out only)
