Chrome Bevelled Glass Style Wall Mount Glass U Clamp - Hole in Glass - 10mm to 12mm Glass

Catalog Number: BCU4CH

Finish: CHROME

Materials: Solid Brass

Glass Thickness Range: 3/8" to 1/2" (10 to 12 mm)

Glass Fabrication Required: BGCU1 Requires Notch; BCU4, BGC037 and BGC039 Require 3/4" (19 mm) Holes

Includes: Mounting Screws and Gaskets

Used to Secure Fixed Panels of Glass for Frameless Shower Enclosures

A Nice Option to More Traditional U-Channel, in that the Clamps Help the Appearance of an 'All-Glass' Look

Glass Fabrication Required to Accommodate Clamps

Bevelled Wall Mount Clamps (Hole-in-Glass Style) mount directly to the wall, ceiling or floor to secure vertical fixed glass panels. Clearance between the glass and the wall is 3/16" (5 mm). Clear silicone can be used to provide a clean, water resistant seal.
